| Wheel Size (mm) | Hole Size (mm) |
Hole Spacing (mm) |
Plate Size (mm) |
Axle thickness (mm) |
Wheel Diameter (mm) |
Wheel Width (mm) |
Swivel radius (mm) |
Load Height (mm) |
Load Capacity (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 25 | 4.0 | 29 X 23 | 38 X 33 | 1.2 | 25 | 14 | 13 | 37 | 10 |
| 30 | 4.0 | 29 X 23 | 38 X 33 | 1.2 | 30 | 14 | 13 | 43 | 15 |
| 38 | 5.2 | 35 X 28.5 | 47 X 40 | 1.2 | 38 | 17 | 16 | 54 | 20 |
| 50 | 6.2 | 46 X 35 | 60 X 48 | 1.5 | 50 | 22 | 21 | 65 | 30 |
| 65 | 7.0 | 51 X 38 | 65 X 54 | 1.5 | 65 | 23 | 25 | 82 | 35 |
| 75 | 8.2 | 50 X 41 | 70 X 58 | 2.0 | 75 | 25 | 32 | 97 | 45 |
