| Wheel Size (mm) | Hole Size (mm) |
Hole Spacing (mm) |
Plate Size (mm) |
Axle thickness (mm) |
Wheel Diameter (mm) |
Wheel Width (mm) |
Swivel radius (mm) |
Load Height (mm) |
Load Capacity (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 50 | 6.5 | 54 X 24 | 65 X 48 | 2.0 | 50 | 21 | 17 | 60 | 50 |
| 65 | 9.0 | 76 X 44.5 | 95 X 70 | 2.3 | 65 | 23 | 21 | 84 | 80 |
| 75 | 8.8 X 11.8 | 83 X 60 | 105 X 80 | 2.3 | 75 | 31 | 23 | 97 | 100 |
