| Wheel Size (mm) | Hole Size (mm) |
Hole Spacing (mm) |
Plate Size (mm) |
Axle thickness (mm) |
Wheel Diameter (mm) |
Wheel Width (mm) |
Swivel radius (mm) |
Load Height (mm) |
Load Capacity (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 50 | 9 x 6.2 | 36 x 36 | 50 x 50 | 1.5 | 50 | 18 | 28 | 72 | 50 |
| 65 | 15 x 8.2 | 49 x 49 | 65 x 65 | 2.0 | 65 | 22 | 32 | 85 | 60 |
| 75 | 15 x 8.2 | 49 x 49 | 65 x 65 | 2.0 | 75 | 23 | 32 | 101 | 70 |
| 100 | 15 x 8.5 | 57 x 57 | 76 x 76 | 2.3 | 100 | 27 | 33 | 134 | 80 |
| 125 | 15 x 8.5 | 57 x 57 | 76 x76 | 2.3 | 125 | 27 | 34 | 157 | 100 |
