| Wheel Size (mm) | Hole Size (mm) |
Hole Spacing (mm) |
Plate Size (mm) |
Axle thickness (mm) |
Wheel Diameter (mm) |
Wheel Width (mm) |
Swivel radius (mm) |
Load Height (mm) |
Load Capacity (kg) |
|---|---|---|---|---|---|---|---|---|---|
| 80 | 8 X 13.5 | 80 X 60 | 102 X 84 | 2.0 | 80 | 22 | 32 | 105 | 50 |
| 100 | 9 X 14 | 80 X 60 | 102 X 84 | 2.0/2.5 | 100 | 27 | 33 | 125 | 60 |
| 125 | 9 X 14 | 80 X 60 | 102 X 84 | 2.0/2.5 | 125 | 33 | 34 | 150 | 80 |
| 160 | 11 X 15 | 105 X 75 | 135 X 105 | 2.5 | 160 | 40 | 43 | 190 | 125 |
| 200 | 11 X 15 | 105 X 75 | 135 X 105 | 2.5 | 200 | 50 | 47 | 235 | 150 |
